Запчасти Komatsu PC308USLC-3E0 ЦИЛИНДР СТРЕЛЫ, ANTI-DROP КЛАПАН ДЛЯ ЦИЛИНДРА СТРЕЛЫ, ЛЕВ. (№-) ЦИЛИНДР СТРЕЛЫ, С ПРЕДОТВРАЩЕНИЕМ СМЕЩЕНИЯ КЛАПАН

|$0

702-21-08330

Valve, Pilot

1

Body, Valve

2

Spool

3

702-21-38510

Case

4

702-21-38420

Retainer, T=2.0mm

4

702-21-38550

Retainer, T=1.7mm

4

702-21-38560

Retainer, T=2.3mm

4

702-21-38610

Retainer, T=1.8mm

4

702-21-38620

Retainer, T=1.9mm

4

702-21-38630

Retainer, T=2.1mm

4

702-21-38640

Retainer, T=2.2mm

5

702-21-38430

Flange

6

702-21-38440

Spring

7

702-21-38650

Spring

8

702-21-38460

O-ring

9

702-21-38470

O-ring

10

702-21-38480

Plug

11

01252-60825

Bolt, Hexagon Socket Head

12

01252-60835

Bolt, Hexagon Socket Head

13

01252-60620

Bolt, Hexagon Socket Head

14

01641-20608

Washer

15

07000-12021

O-ring

16

709-74-92810

Valve

17

709-75-92220

Spring

18

700-93-11320

O-ring

19

700-93-11330

Ring, Back-up

20

723-40-91500

Valve Assembly, Relief

21

700-80-64220

Ring, Back-up

22

700-22-11410

O-ring

23

709-25-11390

O-ring
