Запчасти Komatsu PC308USLC-3E0 МЕХАНИЗМ ПОВОРОТА И МОТОР, (№8-) МЕХАНИЗМ ПОВОРОТА И МОТОР

1

22U-26-21280

Ring

2

07042-00312

Plug, Taper

3

206-26-73310

Case

4

206-26-73150

Bearing

5

206-26-73160

Bearing

6

206-26-73210

Shaft

7

206-26-73140

Spacer

8

07000-15100

O-ring

9

20Y-26-22420

Seal

10

206-26-73120

Cover

11

01010-81040

Bolt

12

01643-31032

Washer

13

07000-15310

O-ring

14

206-26-71480

Carrier

15

206-26-71440

Gear

16

22U-26-21320

Bearing

17

206-26-71520

Washer, Thrust

18

206-26-71510

Pin

19

20Y-26-21330

Pin

20

20Y-26-21240

Plate

21

112-32-11211

Bolt

22

206-26-71452

Gear

23

20K-22-11190

O-ring

24

01010-81440

Bolt

25

01643-31445

Washer, Flat

26

206-26-71430

Gear

27

04260-01270

Ball

28

206-26-71471

Carrier

29

206-26-71420

Gear

30

20Y-27-22210

Bearing

31

22U-26-21230

Washer, Thrust

32

206-26-71210

Pin

33

04064-03515

Ring, Snap

34

206-26-71350

Holder

35

206-26-71410

Gear

36

206-26-71341

Plate

37

02782-10524

Elbow

38

07002-11423

O-ring

39

02896-11015

O-ring

40

02762-005A9

Hose, Face Seal Type

41

02896-11015

O-ring

42

20Y-26-31211

Elbow

43

07040-11409

Plug

44

07002-11423

O-ring

45

01010-81035

Bolt

46

01643-51032

Washer

47

203-26-61350

Filler

48

20Y-26-31420

Filler

49

20Y-26-31430

Packing

50

22U-26-21920

Cap

51

07283-32738

Clip, Pipe

52

04434-51710

Clip

53

01597-01009

Nut

54

01643-31032

Washer

55

01010-81025

Bolt

56

01643-31032

Washer

57

07286-02632

Hose

58

07289-00035

Clamp

59

22U-26-81121

Filler

60

22U-26-21450

Bracket

61

01010-81025

Bolt

62

01643-31032

Washer

63

07000-15250

O-ring

64

01010-82070

Bolt

65

01643-32060

Washer

66

22U-26-21810

Bracket

67

01010-81225

Bolt

68

01643-31232

Washer

69

01010-81250

Bolt

70

01643-31232

Washer

71

04434-52512

Clip

72

20Y-03-11220

Collar

73

01010-81260

Bolt

74

01643-31232

Washer
