Запчасти Komatsu PC308USLC-3E0 МЕХАНИЗМ ПОВОРОТА И МОТОР, ВНУТР. ЧАСТИ, МОТОР ПОВОРОТА (/) (№-) МЕХАНИЗМ ПОВОРОТА И МОТОР

|$0

706-7G-01011

Motor Assembly

|$1

706-7G-03010

Motor Subassembly

1

706-7G-41610

Shaft

2

706-75-42880

Bearing

3

706-75-43810

Spacer

4

706-7E-11260

Spring

5

706-7E-11270

Seat

6

706-76-40890

Bearing

7

706-75-05040

Spacer Kit

7

Spacer, T=3.1mm

|$10

Spacer, T=3.4mm

|$11

Spacer, T=3.7mm

8

04064-04518

Ring, Snap

9

706-7E-11280

Seal, Oil

10

706-7G-41910

Spacer

11

04065-06220

Ring, Snap

12

706-7G-41210

Cylinder Block

13

706-7G-41710

Plate, Valve

14

706-75-43750

Pin, Dowel

15

706-7G-41120

Shaft

16

706-7G-41130

Ring

17

706-7G-41140

Spring

17

706-7G-05010

Retainer Kit

18

Retainer

19

Screw

20

706-7G-41160

Piston Subassembly

21

706-7G-91340

Plate

22

706-7G-91350

Disc

23

706-7G-91110

Piston

24

706-77-40370

O-ring

25

708-8F-31610

O-ring

26

706-7G-91360

Spring
