Запчасти Komatsu PC308USLC-3E0 ОСНОВН. КОНСТРУКЦИЯ, КОНСОЛЬ COVER, ПРАВ. (№-) ОСНОВН. КОНСТРУКЦИЯ, -АКТУАТОР

1

22U-43-23111

Plate

2

21K-06-72240

Wiring Harness

3

22U-43-23120

Bracket

4

22U-43-23130

Plate

5

22U-06-22320

Cover

6

22U-43-23140

Cover

7

22U-06-22420

Potentiometer Assembly

8

22U-06-22470

Knob

9

08086-20000

Switch, Starting

10

22U-06-22480

Plate

11

22U-06-22290

Switch

12

22U-06-22390

Switch, Lamp

13

20Y-06-23920

Clamp

14

08034-10414

Band

15

01023-60408

Screw

16

01023-60512

Screw

17

01023-10508

Screw

18

01023-10512

Screw

19

01601-20513

Washer

20

22U-43-23251

Sheet

21

22U-43-23290

Clip

22

01023-60620

Screw

23

01023-70514

Screw

24

22U-43-23210

Cover

24

20Y-06-31320

Switch Assembly

25

20Y-06-31330

Wiring Harness

26

Plate

27

208-43-71420

Cap

28

22U-43-23230

Cover

29

22U-43-23241

Frame

30

08059-00310

Clip

31

01023-60616

Screw

32

569-06-61960

Relay

33

01435-00612

Bolt

34

01023-60410

Screw

35

22U-43-23711

Cover

36

01023-10614

Screw

37

01643-30623

Washer

38

01010-D1030

Bolt

39

01643-71032

Washer
