Запчасти Komatsu PC308USLC-3E0 ОСНОВН. КОНСТРУКЦИЯ, БЛОК КОНДИЦИОНЕРА (/) (№-) ОСНОВН. КОНСТРУКЦИЯ

|$0

22U-979-1730

Air Conditioner Assembly

|$1

DK534138-6620

Case Assembly

1

DK534136-9201

Case

2

DK53419-0500

Lining

3

DK534461-8802

Cover

4

DK536021-6501

Wiring Diagram

5

DK592024-3100

Clip

6

DK592022-3700

Screw

7

DK595327-8100

Clip

8

DK592022-3700

Screw

9

DK595327-8100

Clip

10

DK595327-3700

Screw

11

DK582623-8500

Sensor

12

DK580534-0400

Clip

13

DK534102-6000

Bracket

14

DK012514-1640

Screw

15

DK582623-1800

Sensor

16

DK580529-7000

Clip

17

DK012155-1440

Screw

18

DK583032-2300

Insulator

18

DK582594-3020

Relay Assembly

19

DK534104-8400

Bracket

20

DK593111-8800

Relay

21

DK593230-1420

Relay

22

DK580140-0600

Screw

23

DK582670-2501

Power Train Assembly

24

DK012514-1640

Screw

25

DK534232-2200

Seal

26

DK502700-2520

Heater Core Assembly

27

DK580534-4300

Clip

28

DK592022-3700

Screw

29

DK524120-1720

Plate Assembly

30

DK534270-8321

Door

31

DK534470-9100

Lever

32

DK580521-6800

Clip

33

DK592055-0900

Clip

34

DK536160-2201

Rod

35

DK012514-1640

Screw

36

DK534189-9200

Lining

37

DK020046-3540

Bolt

38

DK534280-1400

Shaft

39

DK012153-0640

Screw

40

DK534136-9301

Case
