Запчасти Komatsu PC308USLC-3E0 ПОРШЕНЬ НАСОС, ВНУТР. ЧАСТИ (8/) (№-) ПОРШЕНЬ НАСОС

|$0

708-2L-00270

Pump Assembly

|$1

708-2L-01270

Pump Subassembly

1

708-2L-34120

Slider

1

708-2L-06410

Valve Assembly

1

708-2L-06520

Piston Assembly

2

Piston

3

Plug

4

708-2L-35680

Seal

5

708-2L-35621

Plug

6

708-2L-35760

Ball

7

708-2L-35770

Plug

8

708-2L-35690

Seal

9

708-2L-35170

Pin

10

708-2L-35220

Spool

11

708-2L-35630

Retainer

12

708-2L-35641

Seat

13

708-2L-35720

Spring

14

708-2L-35730

Spring

15

708-2L-35650

Seat

16

708-2L-35740

Spring

17

708-2L-34250

Screw

18

07000-B3034

O-ring

19

708-2L-35210

Ring, Back-up

20

708-2L-35710

Seal

21

708-2L-35660

Plug

22

07000-B2010

O-ring

23

07000-B3045

O-ring

24

708-2L-35750

Ring, Back-up

25

708-2L-34230

Cover

26

01580-10806

Nut

27

708-2L-35870

Nut

28

708-2L-35670

Ring, Wire

29

01252-61440

Bolt, Hexagon Socket Head
