Запчасти Komatsu PC308USLC-3 МЕХАНИЗМ ПОВОРОТА (ДЛЯ ПОДАЮЩ.)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

206-26-00501

SWING MACHINERY

1

206-26-73110

CASE

|1

206-26-71490

CASE

2

206-26-73150

BEARING

|2

20Y-26-22330

BEARING

3

206-26-73160

BEARING

|3

206-26-71240

BEARING

4

206-26-73210

SHAFT

|4

206-26-72120

SHAFT

5

206-26-73140

SPACER

6

07000-15100

O-RING

7

20Y-26-22420

SEAL

8

206-26-73120

COVER

9

01010-81040

BOLT

10

01643-31032

WASHER

11

07000-15310

O-RING

12

206-26-71480

CARRIER

13

206-26-71440

GEAR

14

22U-26-21320

BEARING

15

206-26-71520

THRUST WASHER

16

206-26-71510

PIN

17

20Y-26-21330

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT¤ SHOE

20

206-26-71452

GEAR

|20

206-26-71450

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

23

01643-31445

WASHER

24

206-26-71430

GEAR

25

04260-01270

BALL

26

206-26-71470

CARRIER

27

206-26-71420

GEAR

28

20Y-27-22210

BEARING

29

22U-26-21230

WASHER

30

206-26-71210

PIN

31

04064-03515

RING

32

206-26-71350

HOLDER

33

206-26-71410

GEAR

34

206-26-71340

PLATE

35

20Y-26-31510

COVER

36

01010-81035

BOLT

37

01643-51032

WASHER

38

07042-30617

PLUG

39

07042-30108

PLUG
