Запчасти Komatsu PC308USLC-3 МЕХАНИЗМ ПОВОРОТА(№-) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

1

206-26-73110

CASE

|1

206-26-71490

CASE

2

206-26-73150

BEARING

|2

20Y-26-22330

BEARING

3

206-26-73160

BEARING

|3

206-26-71240

BEARING

4

206-26-73210

SHAFT

|4

206-26-72120

SHAFT

5

206-26-73140

SPACER

6

07000-15100

O-RING

7

20Y-26-22420

SEAL

8

206-26-73120

COVER

9

01010-81040

BOLT

10

01643-31032

WASHER

11

07000-15310

O-RING

12

206-26-71480

CARRIER

13

206-26-71440

GEAR

14

22U-26-21320

BEARING

15

206-26-71520

THRUST WASHER

16

206-26-71510

PIN

17

20Y-26-21330

PIN

18

20Y-26-21240

PLATE

19

112-32-11211

BOLT¤ SHOE

20

206-26-71452

GEAR

|20

206-26-71450

GEAR

21

20K-22-11190

O-RING

22

01010-81440

BOLT

23

01643-31445

WASHER

24

206-26-71430

GEAR

25

04260-01270

BALL

26

206-26-71470

CARRIER

27

206-26-71420

GEAR

28

20Y-27-22210

BEARING

29

22U-26-21230

WASHER

30

206-26-71210

PIN

31

04064-03515

RING

32

206-26-71350

HOLDER

33

206-26-71410

GEAR

34

206-26-71340

PLATE

35

07730-40004

VALVE

36

07102-20409

HOSE

37

04434-51912

CLIP

38

20Y-03-11220

COLLAR

39

01010-81260

BOLT

40

01643-31232

WASHER

41

22U-26-81110

BRACKET

42

01010-81225

BOLT

43

01643-31232

WASHER

44

07235-10422

ELBOW

45

07002-12034

O-RING

46

195-04-12280

ELBOW

47

01010-81035

BOLT

48

01643-51032

WASHER

49

22U-26-21280

RING

50

07043-00312

PLUG

51

706-7G-01040

MOTOR ASS'Y

52

203-26-61350

FILLER

53

20Y-26-31420

FILLER

|53

22U-26-21420

FILLER

54

20Y-26-31430

GAUGE

|54

22U-26-21430

GAUGE

55

22U-26-21460

CAP

56

07283-32738

CLIP

57

04434-51710

CLIP

58

01597-01009

NUT

|58

01582-11008

NUT

59

01643-31032

WASHER

60

01010-81025

BOLT

61

01643-31032

WASHER

62

07286-02647

HOSE

63

07289-00035

CLAMP

64

22U-26-81120

FILLER

65

22U-26-21450

BRACKET

66

01010-81025

BOLT

67

01643-31032

WASHER

68

07000-15250

O-RING

69

01010-82070

BOLT

70

01643-32060

WASHER
