Запчасти Komatsu PC300SC-6 ОСНОВН. КЛАПАН (-АКТУАТОР) (8/)(№-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-18300

CONTROL VALVE

|1

709-70-74302

VALVE ASS'Y,SUCTION AND SAFETY

1

SLEEVE

2

SLEEVE

3

POPPET

4

PISTON

5

PLUG

6

POPPET

7

SCREW

8

SPRING

9

SPRING

10

SPRING

11

SEAL

12

SEAL

13

709-25-11390

O-RING

14

O-RING

15

O-RING

16

NUT

|17

709-70-74800

VALVE ASS'Y,SUCTION AND SAFETY

17

SLEEVE

18

SLEEVE

19

POPPET

20

PISTON

21

PLUG

22

POPPET

23

SCREW

24

SPRING

25

SPRING

26

SPRING

27

SEAL

28

SEAL

29

709-25-11390

O-RING

30

O-RING

31

O-RING

32

NUT

|33

709-70-75500

VALVE ASS'Y,SUCTION AND SAFETY

33

SLEEVE

34

SLEEVE

35

POPPET

36

PISTON

37

PLUG

38

POPPET

39

SCREW

40

SPRING

41

SPRING

42

SPRING

43

SEAL

44

SEAL

45

709-25-11390

O-RING

46

O-RING

47

O-RING

48

NUT

|49

709-70-75400

VALVE ASS'Y,SUCTION AND SAFETY

49

SLEEVE

50

SLEEVE

51

POPPET

52

PISTON

53

PLUG

54

POPPET

55

SCREW

56

SPRING

57

SPRING

58

SPRING

59

SEAL

60

SEAL

61

709-25-11390

O-RING

62

O-RING

63

O-RING

64

NUT

|65

723-40-85100

VALVE ASS'Y,SUCTION

65

SLEEVE

66

VALVE

67

SPRING

68

SEAL

69

709-25-11390

O-RING
