Запчасти Komatsu PC300SC-6 РУКОЯТЬ (ПОДУШКА)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

207-957-1260

RETAINER

2

01010-81230

BOLT

3

01643-31232

WASHER

4

207-957-1240

PAD

5

207-957-1710

SHIM

6

207-957-1250

SHIM

7

20Y-957-1210

NUT

8

01245-00616

SCREW

9

20Y-957-1220

PLATE

10

20Y-957-1230

RUBBER

11

01220-40412

SCREW

12

207-957-1720

BRACKET

13

01010-81220

BOLT

14

01643-31232

WASHER

15

207-957-1730

PAD

16

207-957-1740

SHIM

17

01240-00616

SCREW

17A

20Y-957-1220

PLATE

18

20Y-957-1230

RUBBER

19

01220-40412

SCREW

20

207-957-1270

RETAINER

21

01010-81230

BOLT

22

01643-31232

WASHER

23

207-957-1280

PAD

24

207-957-1290

SHIM

25

207-957-1750

SHIM

26

20Y-957-1210

NUT

27

01245-00616

SCREW

28

20Y-957-1220

PLATE

29

20Y-957-1230

RUBBER

30

01220-40412

SCREW

31

207-957-1330

PAD

32

01245-01235

SCREW

33

01643-31232

WASHER

34

203-957-4320

BRACKET

|34

207-957-1340

BRACKET

35

01245-00616

SCREW

36

01643-30623

WASHER

37

20Y-957-1220

PLATE

38

20Y-957-1230

RUBBER

39

01220-40412

SCREW

40

20Y-957-1360

PLATE

41

20Y-957-1371

RUBBER

42

130-43-48540

COLLAR

43

01010-81245

BOLT

44

01643-31232

WASHER
