Запчасти Komatsu PC300SC-6 ОСНОВН. ЛИНИЯ PPC (ДОПОЛН. PPC ЛИНИЯ) ( АКТУАТОР)(№-) ГИДРАВЛИКА
№
Артикул
Название
Примечание
Количество
1
20Y-62-26690
VALVE
|1
07000-01009
O-RING
2
20Y-62-26710
BLOCK
3
20Y-62-26720
VALVE
|3
07000-01009
O-RING
4
20Y-62-26731
VALVE
5
20Y-62-26740
BOLT KIT
6
01252-70880
BOLT
7
205-62-53461
ELBOW
8
07238-10315
CONNECTOR
9
07102-20306
HOSE
10
08034-00536
BAND
11
07103-20313
HOSE
12
207-62-65410
HOSE
13
207-62-65430
HOSE
14
207-62-65440
HOSE
15
20Y-62-22790
BAND¤ RED,RED
16
20Y-62-22810
BAND¤ YELLOW,YELLOW
17
20Y-62-22820
BAND¤ BLUE,BLUE
18
20Y-62-22830
BAND¤ WHITE,WHITE
19
08034-00519
BAND
20
207-62-65420
HOSE
21
20Y-62-22790
BAND¤ RED,RED
22
20Y-62-22820
BAND¤ BLUE,BLUE
23
20Y-62-22830
BAND¤ WHITE,WHITE
24
20Y-62-22840
BAND¤ BLACK,BLACK
25
20Y-62-22850
BAND¤ GREEN,GREEN
26
08034-00519
BAND
27
207-62-65430
HOSE
28
20Y-62-22830
BAND¤ WHITE,WHITE
29
20Y-62-22840
BAND¤ BLACK,BLACK
30
20Y-62-22850
BAND¤ GREEN,GREEN
31
20Y-62-22860
BAND¤ BROWN,BROWN
32
08034-00519
BAND
33
203-62-64910
HOSE¤ 3500MM
34
20Y-62-26651
HOSE
35
20Y-62-22790
BAND¤ RED,RED
36
20Y-62-22810
BAND¤ YELLOW,YELLOW
37
20Y-62-22820
BAND¤ BLUE,BLUE
38
20Y-62-22850
BAND¤ GREEN,GREEN
39
08034-00519
BAND
40
07102-20323
HOSE
41
21N-62-35720
HOSE
42
207-62-65370
HOSE
43
207-62-65460
COVER
44
07235-10315
ELBOW
45
07002-02034
O-RING
Выбрано товаров: 47
