Запчасти Komatsu PC300LL-7E0 T-H ЦИЛИНДР КОВША (заводской номер A8- ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0H771

BUCKET CYLINDER ASSEMBLY

1

707-13-14591

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

707-58-10730

ROD

6

207-63-76170

BUSHING

7

207-70-72120

SEAL, DUST

8

07020-00000

FITTING, GREASE

9

707-27-14690

HEAD

10

176-63-56170

SEAL, DUST

11

07179-13114

RING, SNAP

12

707-52-90780

BUSHING

13

707-75-10160

RING

14

707-51-10030

PACKING, ROD

15

707-51-10640

RING, BUFFER

16

707-35-91420

RING, BACK-UP

17

07000-15130

O-RING

18

01010-81875

BOLT

19

707-41-11840

WASHER

20

707-36-14650

PISTON

21

01310-01216

SCREW

22

707-44-14180

RING, PISTON

23

707-39-14110

RING, WEAR

24

707-44-14910

RING

25

07001-05090

RING, BACK-UP

26

07000-15090

O-RING

27

707-86-11621

TUBE

28

207-63-73180

TUBE

29

07372-21060

BOLT

30

01643-51032

WASHER

31

07000-13035

O-RING

32

207-63-73790

BRACKET

33

707-88-21410

BAND

34

07372-21240

BOLT

35

01643-51232

WASHER

36

707-88-10150

CLAMP

37

01010-81245

BOLT

38

01643-31232

WASHER

39

707-88-33040

CAP

40

07371-31049

FLANGE, SPLIT

41

07372-21035

BOLT

42

01643-51032

WASHER

|$43

707-99-58090

SERVICE KIT, BUCKET CYLINDER
