Запчасти Komatsu PC300LL-7E0 T-H ЦИЛИНДР СТРЕЛЫ(заводской номер A8-A8 ) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

707-01-0A430

BOOM CYLINDER ASSEMBLY

1

707-13-14580

CYLINDER

2

707-76-90490

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

07043-00108

PLUG

6

707-58-10720

ROD

7

707-76-10290

BUSHING

8

07145-00100

SEAL, DUST

9

707-71-34800

COLLAR

10

707-35-91420

RING, BACK-UP

11

07000-15130

O-RING

12

707-71-61090

PLUNGER

13

707-27-14930

HEAD

14

176-63-56170

SEAL, DUST

15

07179-13114

RING, SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING, ROD

18

707-51-10640

RING, BUFFER

19

707-35-91420

RING, BACK-UP

20

07000-15130

O-RING

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14650

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING, PISTON

26

707-39-14110

RING, WEAR

27

707-44-14910

RING

28

07001-05090

RING, BACK-UP

29

07000-15090

O-RING

30

707-86-11580

TUBE, L.H.

|$31

707-86-11590

TUBE, R.H.

31

207-63-54580

TUBE, L.H.

|$33

207-63-54680

TUBE, R.H.

32

01435-01055

BOLT

33

07000-13035

O-RING

34

207-63-54590

BRACKET

35

707-88-21370

BAND

36

01435-01235

BOLT

37

07283-23442

CLIP

38

01643-31032

WASHER

39

01599-01011

NUT

40

01435-01025

BOLT

41

707-88-33040

CAP

42

07371-31049

FLANGE, SPLIT

43

07372-21035

BOLT

44

01643-51032

WASHER

|$47

707-99-58080

SERVICE KIT, BOOM CYLINDER
