Запчасти Komatsu PC300LL-7E0 N-A МОТОР ПОВОРОТА (/) ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$1

706-7K-03030

MOTOR SUBASSEMBLY

1

706-7K-41610

SHAFT

2

706-77-43880

BEARING

3

706-7K-41810

SPACER

4

706-77-42051

SPRING

5

706-77-42041

SEAT

6

706-77-42890

BEARING

7

706-77-05010

SPACER KIT

N/I

NSS

SPACER, 2.3 MM

N/I

NSS

SPACER, 2.5 MM

N/I

NSS

SPACER, 2.7 MM

8

04064-06525

RING, SNAP

9

706-77-43950

SEAL, OIL

10

04065-07525

RING

11

706-7K-41210

BLOCK, CYLINDER

12

706-7K-41710

PLATE, VALVE

13

708-18-13230

PIN

14

706-7K-41120

SHAFT, CENTER

15

706-77-42130

RING, CENTER

16

706-7K-41140

SPRING

|$21

706-7K-05010

RETAINER KIT

17

NSS

RETAINER

18

NSS

SCREW

19

706-7K-41160

PISTON SUBASSEMBLY

20

706-7K-91340

PLATE

21

706-7K-91350

DISC

22

706-7K-91111

PISTON, BRAKE

23

07000-15230

O-RING

24

708-8H-15220

O-RING

25

706-7K-91360

SPRING
