Запчасти Komatsu PC300LL-7E0 H-H ОСНОВН. НАСОС ЗАДН. CRADLE ГИДРАВЛИКА

1

708-2G-12190

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

N/I

708-2G-12310

WASHER, 3.0 MM

N/I

708-2G-12320

WASHER, 3.1 MM

N/I

708-2G-12330

WASHER, 3.2 MM

4

708-1F-12270

RING, SNAP

|$9

708-2G-04270

BLOCK ASSEMBLY, REAR

5

708-2G-13191

BLOCK, CYLINDER

6

NSS

PLATE, VALVE

7

708-18-13230

PIN

8

04065-05520

RING

9

708-2G-13131

SEAT

10

708-2G-13152

SPRING

11

708-2G-13141

SEAT

12

708-2G-13510

GUIDE, RETAINER

13

708-2H-23360

PIN

14

708-2G-13341

RETAINER, SHOE

15

708-2G-13311

PISTON SUBASSEMBLY

|$21

708-2G-04290

CRADLE SUBASSEMBLY

16

708-2G-13613

CRADLE

17

NSS

CAM, ROCKER

18

04020-01434

PIN, DOWEL

19

07000-B1009

O-RING

20

01252-61230

BOLT
