Запчасти Komatsu PC300LC-8M0 РУКОЯТЬ, ЦИЛИНДР КОВША (№8-) РУКОЯТЬ, MM, С -ДОПОЛН. АКТУАТОР ТРУБЫ

|$0

707-E1-01280

Cylinder Assembly

1

707-13-15570

Cylinder

2

707-58-11850

Rod, Piston

3

707-76-90490

Bushing

4

07145-00090

Seal, Dust, (Kit : K15)

5

07020-00000

Fitting, Grease

6

207-70-76170

Bushing

7

207-70-72120

Seal, Dust, (Kit : K15)

8

07020-00000

Fitting, Grease

9

707-27-15620

Head, Cylinder

10

707-56-11740

Seal, Dust, (Kit : K15)

11

07179-13126

Ring, Snap

12

707-51-11860

Packing, Rod, (Kit : K15)

13

707-51-11650

Ring, Buffer, (Kit : K15)

14

707-35-31410

Ring, Back-up, (Kit : K15)

15

07000-B5140

O-ring, (Kit : K15)

16

707-52-90851

Bushing

17

707-75-11040

Ring, Snap

18

01010-82085

Bolt

19

707-88-75310

Washer

20

707-36-15260

Piston

21

707-44-15150

Ring, Piston, (Kit : K15)

22

707-39-15110

Ring, Wear, (Kit : K15)

23

707-44-15911

Ring

24

707-35-31000

Ring, Back-up, (Kit : K15)

25

07000-B5100

O-ring, (Kit : K15)

26

01310-01216

Screw

27

707-86-00920

Tube

28

207-63-73181

Tube

29

07372-21060

Bolt

30

01643-51032

Washer

31

07000-13035

O-ring, (Kit : K15)

32

707-88-22692

Bracket

33

707-88-21420

Band

34

07372-21240

Bolt

35

01643-51232

Washer

36

707-88-10150

Clamp

37

01010-81245

Bolt

38

01643-31232

Washer

39

07371-31049

Flange, Split

40

707-88-33040

Cap

41

07372-21035

Bolt

42

01643-51032

Washer
