Запчасти Komatsu PC300LC-8M0 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, МОТОР ХОДА , ЛЕВ. (/) (№8-) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

207-27-00580

Final Drive Assembly

|$1

708-8H-00440

Motor Assembly

1

708-8H-32180

Shaft

2

708-8H-32150

Bearing

3

708-8H-32170

Bearing

4

708-8H-05050

Spacer Kit

4

Spacer, T=1.6mm

4

Spacer, T=1.7mm

4

Spacer, T=1.8mm

4

Spacer, T=1.9mm

4

Spacer, T=2.0mm

4

Spacer, T=2.1mm

4

Spacer, T=2.2mm

5

708-1F-12281

Seal, Oil

6

708-8H-32160

Spacer

7

04065-07825

Ring, Snap

|$16

708-8H-04860

Cylinder Block Assembly

8

Block, Cylinder

9

Plate, Valve

10

708-18-13230

Pin

11

708-8H-33360

Pin

12

708-8H-33141

Spacer

13

708-8H-33750

Spring

14

04065-06020

Ring, Snap

15

708-8H-33512

Guide, Retainer

16

708-8H-33340

Retainer, Shoe

17

708-8H-33650

Piston Subassembly

18

708-8H-33940

Cam, Rocker

19

04260-02857

Ball, Retainer

20

708-8H-34320

Piston

21

708-8H-34330

Spring

22

708-8H-35130

Plate

23

708-8H-35180

Disc

24

708-8H-35141

Piston, Brake

25

07000-15175

O-ring

26

07001-05175

Ring, Back-up

27

07000-15195

O-ring

28

07001-05195

Ring, Back-up

29

708-8H-35150

Spring
