Запчасти Komatsu PC300LC-8 K-A КАБИНА ПЕРЕДН. ОКНА АНТИВАНДАЛЬН. OPERATOR\XD S ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20Y-53-00031

WINDOW ASSEMBLY

1

20Y-53-11511

FRAME

2

20Y-53-11520

GLASS

3

20Y-54-51531

SEAL

4

20Y-53-11551

SEAL

5

22B-54-15411

LOCK ASSEMBLY

6

22B-54-15440

CASE

7

22B-54-15470

KNOB

8

22B-54-15421

LOCK ASSEMBLY

9

22B-54-15450

CASE

10

22B-54-15480

KNOB

11

01435-40812

BOLT

12

20Y-54-52621

ROLLER

13

20Y-54-52681

ROLLER

14

20Y-53-12330

PIN

15

20Y-54-14590

HANDLE

16

01245-00616

SCREW

17

01643-70623

WASHER

18

20Y-53-12830

BRACKET

19

01245-00816

SCREW

20

01643-70823

WASHER

21

20Y-54-51670

STOPPER

22

20Y-54-51680

STOPPER

23

01252-80616

BOLT

24

01643-70623

WASHER

25

20Y-53-11561

BLOCK ASSEMBLY

26

01245-00816

SCREW

27

01643-70823

WASHER

28

20Y-53-11661

BRACKET

29

01245-00816

SCREW

30

01643-70823

WASHER

31

21J-06-12440

SWITCH

32

01583-11811

NUT

33

20Y-53-11581

BRACKET

34

20Y-53-11641

BRACKET

35

01435-00612

BOLT

36

20Y-54-11611

STOPPER

37

01580-11008

NUT

38

20Y-54-51621

STRIKER

39

01584-31008

NUT

40

01643-71032

WASHER

41

20Y-53-11540

SEAL

42

20Y-54-51420

SEAL

43

20Y-53-12531

COVER

44

20Y-53-12310

COLLAR

45

01245-00616

SCREW

46

01643-70623

WASHER
