Запчасти Komatsu PC300LC-8 A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu PC300LC-8 - A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ
3
9
12
12
14
6
5
12
6
21
15
21
17
7
7
20
20
2
1
11
19
16
4
13
15
18
10
8

Артикул

Название

Примечание

Количество

|$0

6732-21-1960

PLUG, THREADED

1

NSS

PLUG, THREADED

2

6735-21-1970

SEAL, O-RING

3

6743-11-1610

BOLT (M14-2.00x160)

4

6745-11-1811

GASKET, CYLINDER HEAD

|$5

6745-11-1113

HEAD, CYLINDER

|$6

6744-41-4060

KIT, EXHAUST VALVE

5

6732-41-4520

COLLET, VALVE

6

6744-41-4050

RETAINER, VALVE SPRING

7

6744-41-4080

SEAL, VALVE STEM

8

NSS

VALVE, EXHAUST

|$11

6744-41-4040

KIT, INTAKE VALVE

9

6732-41-4520

COLLET, VALVE

10

NSS

VALVE, INTAKE

|$14

6745-11-1121

HEAD, CYLINDER

11

6742-01-2920

PLUG, EXPANSION

12

6735-21-5530

PLUG, EXPANSION

13

NSS

INSERT, VALVE

14

6744-41-4110

PLUG, EXPANSION

15

6744-11-1070

PLUG, EXPANSION

16

6744-41-4120

PLUG, EXPANSION

17

6754-11-1160

PLUG, EXPANSION

18

6745-41-4220

INSERT, VALVE

19

NSS

HEAD, CYLINDER

20

6744-41-4130

GUIDE, VALVE STEM

21

6744-41-4031

SPRING, VALVE

Выбрано товаров: 26
