Запчасти Komatsu PC300LC-8 ЦИЛИНДР СТРЕЛЫ(ДЛЯ СИСТЕМА СМАЗКИ 100 ЧАС.)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

707-01-XY991

CYLINDER GROUP,L.H. (FINAL COATING)

G-2

707-01-XX011

CYLINDER GROUP,R.H. (FINAL COATING)

|$5

707-01-0C581

BOOM CYLINDER ASS'Y

1

707-13-14580

CYLINDER

2

707-76-90390

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00000

FITTING,GREASE

5

07043-00108

PLUG

6

707-58-10720

ROD

7

707-76-10130

BUSHING

8

07145-00100

SEAL,DUST (KIT)

9

707-71-34800

COLLAR

10

707-35-91420

RING,BACK-UP (KIT)

11

07000-15130

O-RING (KIT)

12

707-71-61090

PLUNGER

13

707-27-14890

HEAD

14

176-63-56170

SEAL,DUST (KIT)

15

07179-13114

RING,SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING,ROD (KIT)

18

707-51-10640

RING,BUFFER (KIT)

19

707-35-91420

RING,BACK-UP (KIT)

20

07000-15130

O-RING (KIT)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14650

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING,PISTON (KIT)

26

707-39-14110

RING,WEAR (KIT)

27

707-44-14910

RING

28

07001-05090

RING,BACK-UP (KIT)

29

07000-15090

O-RING (KIT)

30

707-75-10160

RING,SNAP

31

707-86-11580

TUBE,L.H.

31

707-86-11590

TUBE,R.H.

32

207-63-54580

TUBE,L.H.

32

207-63-54680

TUBE,R.H.

33

07372-21060

BOLT

34

01643-51032

WASHER

35

07000-13035

O-RING (KIT)

36

207-63-54590

BRACKET

37

707-88-21370

BAND

38

07372-21240

BOLT

39

01643-51232

WASHER

40

07283-33442

CLIP

41

01643-31032

WASHER

42

01599-01011

NUT

43

01010-81025

BOLT

44

01643-31032

WASHER

45

707-88-33040

CAP

46

07371-31049

FLANGE,SPLIT

47

07372-21035

BOLT

48

01643-51032

WASHER

|$61

707-99-58080

SERVICE KIT
