Запчасти Komatsu PC300LC-7L K-A КЛАПАН PPCДЛЯ ХОД заводской номер A87-A8889 OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-04160

PPC VALVE

1

NSS

BODY, VALVE

2

NSS

VALVE

3

702-16-51140

SHIM, 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-72570

CASE

11

NSS

LEVER

12

NSS

SHAFT

13

NSS

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

04025-00432

PIN, SPRING

18

702-16-54430

BUSHING

19

702-16-54331

WASHER, 1.60MM

|$20

702-16-54341

WASHER, 1.30MM

|$21

702-16-54351

WASHER, 1.00MM

20

702-16-54280

SEAL, DUST

21

702-16-72500

DAMPER ASSEMBLY

22

01252-60525

BOLT

23

702-16-54511

PLATE

24

04025-00420

PIN, SPRING

25

702-16-54520

LEVER

26

01224-40612

SCREW
