Запчасти Komatsu PC300LC-7L K-A КЛАПАН PPCДЛЯ ХОД заводской номер A8-A87 OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-01861

PILOT VALVE

1

NSS

BODY, VALVE

2

NSS

VALVE

3

702-16-51140

SHIM, 0.30 MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-51270

SEAL

9

07000-12020

O-RING

10

702-16-54170

COLLAR

11

702-16-54311

CASE

12

NSS

LEVER

13

NSS

SHAFT

14

NSS

PLATE

15

01010-80855

BOLT

16

01643-30823

WASHER

17

01010-80816

BOLT

18

04025-00432

PIN, SPRING

19

702-16-54430

BUSHING

20

702-16-54331

WASHER, 1.60 MM

|$21

702-16-54341

WASHER, 1.30 MM

|$22

702-16-54351

WASHER, 1.00 MM

21

702-16-54280

SEAL, DUST

22

702-16-54506

DAMPER ASSEMBLY

23

01252-60525

BOLT

24

702-16-54511

PLATE

25

04025-00420

PIN, SPRING

26

702-16-54520

LEVER

27

01224-40612

SCREW
