Запчасти Komatsu PC300LC-7L K7-A БЛОК КОНДИЦИОНЕРА ASSEMBLY заводской номер A8-A87 OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

Схема запчастей Komatsu PC300LC-7L - K7-A БЛОК КОНДИЦИОНЕРА ASSEMBLY заводской номер A8-A87 OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ
44
48
61
43
45
47
17
55
42
30
47
38
40
28
29
47
41
63
53
52
60
46
55
65
16
39
33
49
2
59
1
52
50
58
32
51
55
53
53
23
55
35
32
48
53
56
25
57
36
37
34
55
31
53
47
12
14
5
13
8
62
26
7
57
5
10
11
9
11
22
4
66
18
19
6
3
21
20
27
54
66
24
15
64

Артикул

Название

Примечание

Количество

|$0

ND448800-5222

UNIT, COOLING ASSEMBLY

1

ND245450-2221

CASE, COOLING

2

ND245450-1721

CASE, COOLING

3

ND116569-5010

PLATE

4

ND447600-4970

EVAPORATOR

5

ND949142-0030

O-RING

6

ND116120-7990

CORE ASSEMBLY, HEATER

7

ND447500-1390

VALVE, EXPANSION

8

ND949046-2150

BOLT

9

ND446870-5650

TUBE, ACCESSORY

10

ND949142-0030

O-RING

11

ND949142-0010

O-RING

12

ND077500-0710

THERMISTOR

13

ND246690-2840

CLAMP

14

ND116650-8800

DOOR ASSEMBLY

15

ND116650-8820

DOOR ASSEMBLY

16

ND116650-8840

DOOR ASSEMBLY

17

ND116640-4652

DAMPER ASSEMBLY

18

ND443440-0030

SWITCH, PRESSURE

19

ND949142-0040

O-RING

20

ND446830-3880

TUBE

21

ND446810-9520

TUBE, SUCTION

22

ND949142-0030

O-RING

23

ND146678-4930

PACKING

24

ND949321-9940

GROMMET

25

ND246770-6990

CLAMP, PIPING

26

ND017231-1400

CLAMP

27

ND017660-3490

BRACKET

28

ND170400-4310

SENSOR ASSEMBLY, THERMO

29

ND146690-6020

CLAMP

30

ND246634-6010

BRACKET

31

ND499300-2051

I.C. POWER

32

ND063700-7200

SERVO MOTOR ASSEMBLY

33

ND063700-7210

SERVO MOTOR ASSEMBLY

34

ND116569-5020

PLATE

35

ND116682-0930

LEVER

36

ND116682-0960

LEVER

37

ND116662-4850

SHAFT

38

ND116569-5030

PLATE

39

ND116682-0940

LEVER

40

ND116682-0951

LEVER

41

ND116569-5041

PLATE

42

ND116569-5051

PLATE

43

ND116662-4860

SHAFT

44

ND116569-5062

PLATE

45

ND116682-0920

LEVER

46

ND116682-0910

LEVER

47

ND949008-0460

SCREW, TAPPING

48

17M-911-3290

CLAMP

49

ND146535-1311

BRACKET

50

ND146535-0411

BRACKET

51

ND146525-6070

BRACKET

52

ND91310-03081

SCREW, WASHER

53

ND949001-1730

SCREW, TAPPING

54

ND90930-05121

SCREW, TAPPING

55

ND90930-06141

SCREW, TAPPING

56

ND146535-0421

BRACKET

57

ND90930-05161

SCREW, TAPPING

58

ND116682-3440

LEVER

59

ND017730-8380

LEVER, CONTROL

60

ND116660-2700

DOOR ASSEMBLY

61

ND146698-6930

PACKING

62

ND146698-6950

PACKING

63

ND146698-8480

PACKING

64

ND146637-5650

PACKING

65

ND146637-0712

PACKING

66

ND146637-3880

PACKING

Выбрано товаров: 67
