Запчасти Komatsu PC300LC-7L K-A КАБИНА ПЕРЕДН. ВЕРХН. ОКНА заводской номер A8-A87 OPERATOR ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$1

20Y-54-01132

WINDOW ASSEMBLY

|$2

20Y-54-52600

WINDOW ASSEMBLY

1

NSS

FRAME, FRONT WINDOW

2

20Y-54-51522

GLASS, FRONT

3

20Y-54-51531

SEAL, FRONT WINDOW

4

20Y-54-51551

SEAL, FRONT LOWER

5

22B-54-15411

LOCK ASSEMBLY, LEFT HAND

6

22B-54-15440

CASE, LEFT HAND

7

22B-54-15470

KNOB, LEFT HAND

8

22B-54-15421

LOCK ASSEMBLY, RIGHT HAND

9

22B-54-15450

CASE, RIGHT HAND

10

22B-54-15480

KNOB, RIGHT HAND

11

01435-40812

BOLT

12

01435-40820

BOLT

13

20Y-54-52621

ROLLER

14

20Y-54-52681

ROLLER

15

20Y-54-52691

PIN, LEFT HAND

16

20Y-54-14590

HANDLE

17

01023-10616

SCREW

18

20Y-54-52632

BRACKET

19

20Y-54-52642

BRACKET

20

01245-00616

SCREW

21

01643-70623

WASHER

22

20Y-54-51670

STOPPER

23

20Y-54-51680

STOPPER

24

01252-80616

BOLT

25

01643-70623

WASHER

26

20Y-54-51633

BLOCK, LEFT HAND

27

20Y-54-52192

BLOCK, RIGHT HAND

28

01252-80620

BOLT

29

01641-50608

WASHER

30

20Y-54-51652

BLOCK, LEFT HAND

31

20Y-54-52282

BLOCK, LEFT HAND

32

20Y-54-51663

BLOCK, RIGHT HAND

33

22B-54-15621

STOPPER

34

01224-70612

SCREW

35

01252-80616

BOLT

36

01641-50608

WASHER

37

22B-54-15432

STRIKER SASH

38

01435-40616

BOLT

39

21J-06-12440

SWITCH

40

01583-11811

NUT

41

20Y-54-11611

STOPPER

42

01580-11008

NUT

43

20Y-54-52491

PLATE

44

01435-40612

BOLT

45

20Y-54-51622

STRIKER

46

20Y-54-51541

TRIM FRONT

47

20Y-54-51591

SPRING ASSEMBLY

48

01435-00616

BOLT

49

20Y-54-51640

HOLDER

50

20Y-54-51420

SEAL

51

20Y-54-52940

PLATE
