Запчасти Komatsu PC300LC-7L H-A ОСНОВН. НАСОС ПЕРЕДН. БЛОК ЦИЛИНДРОВ ГИДРАВЛИКА

1

708-2G-12111

SHAFT, FRONT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

4

708-1F-12270

RING, SNAP

5

708-2G-12220

SEAL, OIL

6

708-8H-32160

SPACER

7

04065-07825

RING, SNAP

|$9

708-2G-04141

BLOCK ASSEMBLY, FRONT

8

NSS

BLOCK, CYLINDER

9

NSS

PLATE, VALVE

10

708-18-13230

PIN

11

04065-05520

RING, SNAP

12

708-2G-13131

SEAT

13

708-2G-13152

SPRING

14

708-2G-13141

SEAT

15

708-2G-13510

GUIDE, RETAINER

16

708-2H-23360

PIN

17

708-2G-13341

RETAINER, SHOE

18

708-2G-13311

PISTON SUB ASSEMBLY

|$21

708-2G-04161

CRADLE ASSEMBLY

19

NSS

CRADLE

20

NSS

CAM, ROCKER

21

04020-01434

PIN

22

07000-B1009

O-RING

23

01252-61230

BOLT
