Запчасти Komatsu PC300LC-7L H-A ОСНОВН. КЛАПАН АКТУАТОР - КЛАПАН СЕКЦ. - PRESSURE COMPENSATION КЛАПАН ГИДРАВЛИКА

|$1

723-40-66300

VALVE ASSEMBLY, LOAD SENSING

1

NSS

CASE

2

NSS

SEAT

3

NSS

SEAT

4

NSS

BALL

5

NSS

PLUG

|$7

723-90-76501

VALVE ASSEMBLY, PRESSURE COMPENSATION

6

NSS

SLEEVE

7

NSS

SLEEVE

8

NSS

POPPET

9

NSS

SEAL

10

NSS

PISTON

11

NSS

SLEEVE

12

NSS

POPPET

13

NSS

UNION

14

NSS

PISTON

15

NSS

SPRING

16

NSS

SPRING

17

NSS

SPRING

18

NSS

SEAL

19

NSS

SEAL

20

07000-13024

O-RING

21

NSS

O-RING

22

NSS

NUT

23

NSS

NUT

24

NSS

HOLDER

25

NSS

O-RING

26

NSS

SPRING

27

NSS

O-RING

|$30

723-90-61700

VALVE ASSEMBLY, PRESSURE COMPENSATION

28

NSS

SLEEVE

29

NSS

SLEEVE

30

NSS

POPPET

31

NSS

PISTON

32

NSS

PLUG

33

NSS

POPPET

34

NSS

SPACER

35

NSS

SPRING

36

NSS

SPRING

37

NSS

SPRING

38

NSS

SEAL

39

NSS

SEAL

40

07000-13024

O-RING

41

NSS

O-RING

42

NSS

O-RING

43

NSS

NUT

44

NSS

NUT
