Запчасти Komatsu PC300LC-7L H-A ОСНОВН. КЛАПАН ВСАСЫАЮЩИЙ КЛАПАН БЕЗОПАСНОСТИS ГИДРАВЛИКА

|$1

723-40-91200

VALVE ASSEMBLY, SUCTION AND SAFETY

1

NSS

SLEEVE

2

NSS

SLEEVE

3

NSS

POPPET

4

NSS

PISTON

5

NSS

PLUG

6

NSS

POPPET

7

NSS

SPACER

8

NSS

SPRING

9

NSS

SPRING

10

NSS

SPRING

11

NSS

SEAL

12

NSS

SEAL

13

709-25-11390

O-RING

14

NSS

O-RING

15

NSS

O-RING

16

NSS

NUT

17

NSS

NUT

|$19

723-90-76201

VALVE ASSEMBLY, SUCTION AND SAFETY

18

NSS

SLEEVE

19

NSS

SLEEVE

20

NSS

POPPET

21

NSS

SEAL

22

NSS

PISTON

23

NSS

SLEEVE

24

NSS

POPPET

25

NSS

UNION

26

NSS

PISTON

27

NSS

SPRING

28

NSS

SPRING

29

NSS

SPRING

30

NSS

SEAL

31

NSS

SEAL

32

07000-13024

O-RING

33

NSS

O-RING

34

NSS

NUT

35

NSS

NUT

36

NSS

HOLDER

37

NSS

O-RING

38

NSS

SPRING

39

NSS

O-RING

|$42

723-40-85100

VALVE ASSEMBLY, SUCTION

40

NSS

SLEEVE

41

NSS

VALVE

42

NSS

SPRING

43

NSS

SEAL

44

709-25-11390

O-RING
