Запчасти Komatsu PC300LC-7E0 ОСНОВН. НАСОС (ЗАДН. CRADLE) ГИДРАВЛИКА

|$0

708-2G-00700

PUMP ASS'Y,(SEE FIG. H0210-02H0)

|$1

708-2G-01070

PUMP SUB ASS'Y,(SEE FIG. H0210-02H0)

1

708-2G-12190

SHAFT

2

708-2G-12251

BEARING

3

708-2G-05010

WASHER KIT

|$5

WASHER¤ 3.0MM

|$6

WASHER¤ 3.1MM

|$7

WASHER¤ 3.2MM

4

708-1F-12270

RING

|$9

708-2G-04270

BLOCK ASS'Y,REAR

5

BLOCK,CYLINDER

6

PLATE,VALVE

7

708-18-13230

PIN

8

04065-05520

RING

9

708-2G-13131

SEAT

10

708-2G-13152

SPRING

11

708-2G-13141

SEAT

12

708-2G-13510

GUIDE,RETAINER

13

708-2H-23360

PIN

14

708-2G-13341

RETAINER,SHOE

15

708-2G-13311

PISTON SUB ASS'Y

|$21

708-2G-04290

CRADLE SUB ASS'Y

16

CRADLE

17

CAM,ROCKER

18

04020-01434

PIN,DOWEL

19

07000-B1009

O-RING

20

01252-61230

BOLT
