Запчасти Komatsu PC300LC-7E0 PPC ХОД КЛАПАН (/) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

702-16-04250

PILOT VALVE

1

BODY

2

VALVE

3

702-16-51140

SHIM¤ 0.30MM

4

702-16-53420

SPRING

5

702-16-53140

RETAINER

6

702-16-54420

SPRING

7

702-16-53170

PISTON

8

702-16-71150

SEAL

9

702-16-71160

SEAT

10

702-16-73630

CASE

11

LEVER

12

SHAFT

13

PLATE

14

01010-80855

BOLT

15

01643-30823

WASHER

16

01010-80816

BOLT

17

702-16-54331

WASHER¤ 1.60MM

|$18

702-16-54341

WASHER¤ 1.30MM

|$19

702-16-54351

WASHER¤ 1.00MM

|$20

702-16-54380

PLATE

|$21

702-16-56390

WASHER¤ 2.20MM

18

04025-00432

PIN

19

702-16-54430

BUSHING

20

07000-12018

O-RING

21

702-16-73610

DAMPER ASS'Y

22

01023-10306

SCREW

23

702-16-73650

PIN

24

04022-04016

PIN
