Запчасти Komatsu PC300LC-7E0 ОХЛАЖД-Е (РАДИАТОР И МАСЛООХЛАДИТЕЛЬ) СИСТЕМА ОХЛАЖДЕНИЯ

1

207-03-75120

RADIATOR ASS'Y

2

20Y-03-22110

CAP

3

205-03-71230

HOSE

4

20Y-03-11330

CLIP

5

205-03-62660

PLUG

6

07000-11007

O-RING

7

208-03-71730

SEAL

8

208-03-71810

SEAL

9

208-03-71840

SEAL

10

201-03-29160

SPACER

11

07002-12434

O-RING

12

201-910-6730

CUSHION

13

207-03-75590

PLATE

14

01010-81045

BOLT

15

01643-31032

WASHER

16

207-03-75171

FRAME

17

207-03-75181

FRAME

18

208-03-71210

FRAME

19

01010-81225

BOLT

20

01643-31232

WASHER

21

208-03-71221

FRAME

22

01010-81025

BOLT

23

01643-31032

WASHER

24

01010-81020

BOLT

25

01643-31032

WASHER

26

22B-03-12590

CUSHION

27

208-03-71380

CUSHION

28

208-03-71480

SEAL

29

208-03-71490

SEAL

30

208-03-71780

SEAL

31

208-03-71790

SEAL

32

208-03-71821

SEAL

33

208-03-71830

SEAL

34

208-03-71131

OIL COOLER

35

208-03-71141

OIL COOLER

36

208-03-71151

OIL COOLER

37

208-03-71190

FRAME

38

208-03-71680

SEAL

39

208-03-71690

SEAL

40

208-03-71850

SEAL

41

208-03-71860

SEAL

42

208-03-71870

SEAL

43

208-03-71880

SEAL

44

208-03-71890

SEAL

45

01011-81205

BOLT

46

01010-81020

BOLT

47

01643-31032

WASHER

48

01643-31232

WASHER

49

07000-13045

O-RING

50

01010-81025

BOLT

51

01643-31032

WASHER
