Запчасти Komatsu PC300LC-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№89-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-48-16601

CONTROL VALVE

|1

723-48-16600

CONTROL VALVE

|1

723-48-16202

CONTROL VALVE

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1664-41A0 TO Y1664-55A0.

|1

BODY SUB ASS'Y

1

BLOCK,VALVE

2

SPOOL

3

723-46-15390

PLUG

4

723-46-15370

RETAINER

5

723-46-15380

RETAINER

6

723-46-14110

SPRING

7

723-46-15360

CASE

8

07430-71380

O-RING

9

01252-30820

BOLT

10

SPOOL

11

723-46-15330

BOLT

12

PISTON

13

SEAL

14

SEAL

15

723-46-14180

SPRING

16

723-46-15310

CASE

17

723-46-15320

CASE

18

07000-01006

O-RING

19

706-73-71450

PLUG

20

07002-01423

O-RING

21

07430-71380

O-RING

22

01252-60845

BOLT

23

07000-12015

O-RING

24

07000-12018

O-RING

25

07000-13032

O-RING

26

07000-03040

O-RING
