Запчасти Komatsu PC300LC-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№9-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

723-47-16501

CONTROL VALVE

|1

723-47-16500

CONTROL VALVE

|1

723-47-16103

CONTROL VALVE

|1

723-47-16102

CONTROL VALVE

|1

723-47-16101

CONTROL VALVE

|$$6

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1662-21A0 TO Y1662-32A0.

|1

723-40-50300

VALVE ASS'Y,RELIEF

1

SLEEVE

2

VALVE

3

POPPET

4

SPRING

5

SCREW

6

SPRING

7

PLUG

8

NUT

9

700-22-11410

O-RING

10

700-80-64220

RING

11

07002-02434

O-RING

12

07000-02011

O-RING

|13

723-40-50301

VALVE ASS'Y,RELIEF

13

SLEEVE

14

SEAT

15

VALVE

16

POPPET

17

SPRING

18

HOLDER

19

SCREW

20

SPRING

21

PLUG

22

NUT

23

NUT

24

700-22-11410

O-RING

25

700-80-64220

RING

26

07002-02434

O-RING

27

O-RING

28

O-RING

29

RING

30

O-RING
