Артикул
Название
Примечание
Количество
|1
706-77-01281
MOTOR ASS'Y
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1640-11A0 AND Y1640-12A0.
|1
706-77-03130
MOTOR SUB ASS'Y
1
706-77-43210
CASE,MOTOR
2
706-77-72610
HOUSING
3
706-75-42830
PIN,DOWEL
4
706-77-72170
PLUG
5
07002-12434
O-RING
6
706-73-71450
PLUG
7
07002-11423
O-RING
8
706-7G-40010
BEARING
9
706-7E-11440
O-RING
10
706-77-43180
BOLT
11
706-77-43860
SHAFT
12
706-77-43880
BEARING
13
706-77-42890
BEARING
14
706-77-42051
SPRING
15
706-77-42041
SEAT
16
706-77-05010
SPACER KIT
|16
SPACER¤ 2.3MM
|16
SPACER¤ 2.5MM
|16
SPACER¤ 2.7MM
17
04064-06525
RING,SNAP
18
706-77-43950
SEAL,OIL
19
706-77-43060
COVER
20
07000-02125
O-RING
21
04071-00130
RING,SNAP
22
706-77-43191
BLOCK,CYLINDER
23
706-77-43840
PLATE,VALVE
24
708-18-13230
PIN
25
706-77-43080
SHAFT,CENTER
26
706-77-42130
RING,CENTER
27
706-77-42110
SPRING
|28
706-77-05050
RETAINER KIT
28
RETAINER
29
SCREW
30
706-77-42160
PISTON SUB ASS'Y
31
706-77-91540
PLATE
32
706-77-91550
DISC
33
706-77-91580
PISTON,BRAKE
34
07000-15180
O-RING
35
708-8H-15220
O-RING
36
706-77-91510
SPRING
Выбрано товаров: 43
