Запчасти Komatsu PC300LC-6Z МОТОР ПОВОРОТА (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

|1

706-77-01271

MOTOR ASS'Y

|1

706-77-01170

MOTOR ASS'Y

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.Y1640-01A0 AND Y1640-02A0.

|1

702-77-04102

VALVE ASS'Y,RELIEF

1

SLEEVE

2

VALVE

3

SEAL

4

SEAL

5

SPRING

6

SPRING

7

SCREW

8

O-RING

9

RING,BACK-UP

10

NUT

11

706-77-72540

SPRING

12

706-77-72520

COVER

13

07000-13042

O-RING

14

01010-81275

BOLT

15

01643-31232

WASHER

|16

702-15-75000

VALVE ASS'Y

16

BODY

17

SPOOL

18

SEAL

19

SPRING

20

PLUG

21

O-RING

22

07000-13042

O-RING

23

07000-11007

O-RING

24

01252-60825

BOLT
