Запчасти Komatsu PC300LC-6Z ЦИЛИНДР СТРЕЛЫ(КЛАПАН ПЕРЕГРУЗКИ)(№78-) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ

G-1

207-63-X9060

BOOM CYLINDER GROUP,L.H.

G-1

207-63-X9070

BOOM CYLINDER GROUP,R.H.

|$$3

====================

|1

207-63-02600

BOOM CYLINDER ASS'Y

1

207-63-53541

CYLINDER

2

707-76-90450

BUSHING

3

07145-00090

SEAL,DUST (KIT)

4

07020-00675

FITTING,GREASE

5

07043-00108

PLUG

6

207-63-53520

ROD

7

707-76-10130

BUSHING

8

07145-00100

SEAL,DUST (KIT)

9

707-71-32880

COLLAR

10

707-35-91420

RING,BACK-UP (KIT)

11

07000-15130

O-RING (KIT)

12

707-71-61060

PLUNGER

13

707-27-14930

HEAD

14

176-63-56170

SEAL,DUST (KIT)

15

07179-13114

RING,SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING,ROD (KIT)

18

707-51-10630

RING,BUFFER (KIT)

19

707-35-91420

RING,BACK-UP (KIT)

20

07000-15130

O-RING (KIT)

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14410

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING,PISTON (KIT)

26

707-39-14820

RING,WEAR (KIT)

27

707-44-14910

RING

28

07001-05090

RING,BACK-UP (KIT)

29

07000-15090

O-RING (KIT)

30

207-63-53571

TUBE,L.H.

|30

207-63-53671

TUBE,R.H.

31

01435-01055

BOLT

32

07000-13035

O-RING (KIT)

33

707-88-95731

BRACKET

34

707-88-95720

BAND

35

01010-81240

BOLT

36

01643-51232

WASHER

37

07283-23442

CLIP

38

01643-31032

WASHER

39

01599-01011

NUT

40

707-88-33040

CAP

41

07371-31049

FLANGE,SPLIT

42

07372-21035

BOLT

43

01643-51032

WASHER

|$$49

====================

|K

707-99-58360

SERVICE KIT
