Запчасти Komatsu PC300LC-6LE FIG. A-AB СТАРТЕР - DELCO REMY 999 MT - ТИП - V ДВИГАТЕЛЬ

|$0

6743-82-6130

MOTOR, STARTING PRODUCTION

|$1

1243 215 H92

MOTOR, STARTING SERVICE

1

1277 066 H1

LEAD, C.E. TERMINAL TO SOLENOID SWITCH

|$3

NSS

NUT, SHUNT LEAD TO SWITCH

2

1316 560 H1

SWITCH, SOLENOID

|$5

1283 448 H1

SCREW AND WASHER, SWITCH MOUNTING

3

1228 450 H1

PLUNGER, SOLENOID

4

1210 070 H1

WASHER, RETAINER

5

1210 071 H1

BOOT, PLUNGER

6

1210 072 H1

RETAINER, PLUNGER SPRING

7

1210 073 H1

SPRING, PLUNGER

8

1210 074 H1

RETAINER, PLUNGER SPRING

|$12

1223 258 H91

HOUSING ASSEMBLY, LEVER

9

213 262 R1

RING, RETAINER

10

355 967 R1

O-RING

11

1211 152 H1

SHAFT, SHIFT LEVER

12

352 219 R1

O-RING

13

1211 285 H1

SEAL, OIL

14

NSS

HOUSING, LEVER

|$19

1245 107 H1

SCREW, LEVER HOUSING

15

NSS

HOUSING

16

NSS

WASHER, SPACER - D.E.

17

NSS

O-RING

18

NSS

O-RING

19

NSS

CUP, OIL RESERVOIR - LEVER HOUSING

20

NSS

WICK, OIL RESERVOIR - LEVER HOUSING

21

NSS

GASKET, INSPECTION PLUG

22

1210 066 H1

PLUG, INSPECTION

23

NSS

NUT, PLUNGER ROD GUIDE ADJUSTING

24

NSS

RING, SNAP - SHIFT LEVER SHAFT

25

NSS

BUSHING, LEVER HOUSING

26

NSS

WASHER, BRAKE

27

NSS

LEVER, SHIFT

28

1228 604 H1

DRIVE ASSEMBLY

|$34

1223 260 H91

HOUSING ASSEMBLY, D.E.

29

347 360 R1

O-RING

30

NSS

HOUSING, D.E.

|$37

1245 105 H1

SCREW, DRIVE HOUSING

31

1211 288 H1

BUSHING, DRIVE HOUSING

32

NSS

WICK, OIL RESERVOIR - D.E.

33

NSS

CUP, OIL RESERVOIR - D.E.

34

NSS

O-RING

35

1223 265 H1

TERMINAL AND LEAD ASSEMBLY

36

NSS

SPRING, BRUSH

37

NSS

BRUSH

|$45

NSS

SCREW - BRUSH AND FIELD COIL LEAD TO BRUSH

38

1284 360 H91

PLATE ASSEMBLY, BRUSH

39

NSS

WASHER, THRUST

40

1228 452 H1

CONNECTOR

|$49

1211 267 H1

NUT, FIELD COIL CONNECTOR TO SWITCH

|$50

1283 448 H1

SCREW AND WASHER, CONNECTOR TO FIELD ATTACH

41

1210 062 H1

INSULATOR, FIELD TERMINAL

42

1210 061 H1

INSULATOR, FIELD TERMINAL

43

1228 453 H1

INSULATOR, FIELD COIL

44

1223 256 H1

ARMATURE

45

1228 454 H1

PIN, SPRING

46

1211 263 H1

SHOE, POLE

47

1245 108 H1

SCREW, POLE SHOE

48

1211 271 H1

INSULATOR, FIELD COIL

49

1228 605 H1

COIL ASSEMBLY

50

1223 269 H91

PACKAGE, SERVICE INSULATION - C.E. TERMINAL

51

NSS

CUP, OIL RESERVOIR - C.E.

52

NSS

WICK, OIL RESERVOIR - C.E.

53

1223 255 H1

HOUSING, C.E.

|$64

120 238

NUT, TERMINAL - C.E.

|$65

1211 267 H1

NUT AND WASHER, C.E. FRAME

|$66

120 239

WASHER, LOCK - TERMINAL STUD C.E.

|$67

120 396

WASHER, TERMINAL - C.E. FRAME

54

NSS

BUSHING, COVER

|$69

1305 530 H1

SHIELD, TERMINAL

|$70

1305 531 H1

NUT, HEX

|$71

09842-A0481

DECAL, DO NOT JUMP START

|$72

1223 266 H91

KIT, SERVICE - BUSHINGS

|$73

1223 267 H91

KIT, SERVICE - SHIFT LEVER

|$74

1223 268 H91

KIT, SERVICE - 24V BRUSH
