Запчасти Komatsu PC300LC-6LE FIG. T-A ЦИЛИНДР КОВША - 78 MM (8.8 IN.) УДЛИНН. ЦИЛИНДР BARREL РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

207-63-09040

CYLINDER ASSEMBLY, BUCKET

1

207-63-73341

BARREL, CYLINDER

2

707-76-90130

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00000

FITTING, GREASE

5

207-63-73320

ROD

6

207-63-76170

BUSHING

7

205-70-62180

SEAL

8

07020-00000

FITTING, GREASE

9

707-27-14930

HEAD

10

176-63-56170

SEAL, DUST

11

07179-13114

RING, SNAP

12

707-52-90780

BUSHING

13

707-51-10030

PACKING, ROD

14

707-51-10630

RING

15

707-35-91420

RING, BACK-UP

16

07000-15130

O-RING

17

01010-81875

BOLT

18

707-41-11840

WASHER

19

707-36-14410

PISTON

20

01310-01216

SCREW, SET

21

707-44-14180

RING, PISTON

22

707-39-14820

RING, WEAR

23

707-44-14910

RING

24

07001-05090

RING, BACK-UP

25

07000-15090

O-RING

26

207-63-73371

TUBE

27

207-63-73180

TUBE

28

01435-01055

BOLT

29

07000-13035

O-RING

30

707-88-87180

BRACKET

31

707-88-87170

CLAMP, CYLINDER

32

01010-81240

BOLT

33

01643-51232

WASHER

34

707-88-10150

CLAMP

35

01010-81245

BOLT

36

01643-31232

WASHER
