Запчасти Komatsu PC300LC-6LE FIG. T-A ЦИЛИНДР РУКОЯТИ- MM (9.7 IN.) УДЛИНН. ЦИЛИНДР BARREL (УСИЛ.) РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

207-63-02341

CYLINDER ASSEMBLY, ARM

1

207-63-63541

CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL, DUST

4

207-63-63520

ROD, CYLINDER

5

707-76-10130

BUSHING

6

07145-00100

SEAL, DUST

7

707-71-31191

COLLAR

8

707-71-31181

COLLAR

9

07001-05155

RING, BACK-UP

10

07000-15155

O-RING

11

707-71-61100

PLUNGER

12

707-71-11150

RING, BACK-UP

13

707-71-60250

PLUNGER

14

04260-00635

BALL

15

01312-01220

SCREW, SET

16

707-27-16620

HEAD

17

198-63-94170

SEAL, DUST

18

07179-13126

RING, RETAINING

19

707-52-90860

BUSHING

20

707-51-11030

PACKING, ROD

21

707-51-11630

RING, BUFFER

22

07001-05155

RING, BACK-UP

23

07000-15155

O-RING

24

01010-82085

BOLT

25

707-88-75310

WASHER

26

707-36-16320

PISTON

27

707-40-16870

SPACER

28

01252-31450

BOLT

29

707-44-16180

RING, PISTON

30

707-39-16820

RING, WEAR

31

707-44-16910

RING

32

707-35-52930

RING, BACK-UP

33

07000-12090

O-RING

34

207-63-63570

TUBE

35

01010-81060

BOLT

36

01643-31032

WASHER

37

07000-13035

O-RING

38

707-88-95751

BRACKET

39

707-88-95740

CLAMP

40

707-88-95781

BRACKET

41

707-88-95770

CLAMP

42

01010-81240

BOLT

43

01643-31232

WASHER

44

07283-23442

U-BOLT

45

01643-31032

WASHER

46

01599-01011

NUT

47

07020-00900

FITTING, GREASE

48

207-63-63180

TUBE
