Запчасти Komatsu PC300LC-6LE FIG. T-AA ЦИЛИНДР РУКОЯТИASSEMBLY - 79 MM (9 IN.) УДЛИНН. ЦИЛИНДР BARREL - СТАНДАРТН. РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

207-63-09030

CYLINDER ASSEMBLY, BOOM

1

207-63-63741

BARREL, CYLINDER

2

707-76-10130

BUSHING

3

07145-00100

SEAL, DUST

4

207-63-63721

ROD

5

707-76-10130

BUSHING

6

07145-00100

SEAL, DUST

7

707-71-32800

COLLAR

8

707-35-91640

RING

9

07000-15150

O-RING

10

707-71-61111

PLUNGER

11

707-71-60250

PLUNGER

12

04260-00635

BALL

13

707-71-91270

CAP

14

707-27-16920

HEAD

15

198-63-94170

SEAL, DUST

16

07179-13126

RING, SNAP

17

707-52-90850

BUSHING

18

707-51-11030

PACKING, ROD

19

707-51-11630

RING, BUFFER

20

707-35-91640

RING

21

07000-15150

O-RING

22

01010-82085

BOLT

23

707-88-75310

WASHER

24

707-36-16380

PISTON

25

01310-01216

SCREW

26

707-44-16180

RING

27

707-39-16820

RING

28

707-44-16910

RING

29

07001-05100

RING

30

07000-15100

O-RING

31

207-63-63771

TUBE

32

207-63-63180

TUBE

33

01435-01055

BOLT

34

07000-13035

O-RING

35

707-88-95750

BRACKET

36

707-88-95740

CLAMP, CYLINDER

37

707-88-95781

BRACKET

38

707-88-95770

CLAMP, CYLINDER

39

01010-81240

BOLT

40

01643-51232

WASHER

41

07283-23442

U-BOLT

42

01643-31032

WASHER

43

01599-01011

NUT

44

07000-13032

O-RING

45

07378-11000

HEAD

46

07371-31049

FLANGE, SPLIT

47

07372-21035

BOLT

48

01643-51032

WASHER
