Запчасти Komatsu PC300LC-6LE FIG. P-A МОТОР ХОДА - КОРПУС ASSEMBLY - УСИЛ. НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$1

706-88-00020

COVER SUB ASSEMBLY

1

706-88-40370

O-RING

2

07000-12012

O-RING

3

706-88-40310

BOLT

4

706-88-40660

SHAFT, DRIVE

5

706-88-40880

BEARING

6

706-88-40890

BEARING

7

706-88-40810

RETAINER

8

706-88-05010

KIT, SPACER

|$10

NSS

SPACER, 1.6 MM

|$11

NSS

SPACER, 1.7 MM

|$12

NSS

SPACER, 1.8 MM

9

04064-07525

RING, SNAP

10

708-8K-12141

SEAL, OIL

11

706-88-40710

HOUSING

12

07000-02135

O-RING

13

04071-00140

RING, SNAP

14

708-88-40090

BLOCK, CYLINDER

15

706-88-40080

SHAFT, CENTER

16

706-88-40130

RING, CENTER

17

706-88-40060

SPRING

|$22

706-88-05020

KIT, RETAINER

18

706-88-40260

RETAINER

19

708-23-12350

SCREW

20

706-88-40161

PISTON ASSEMBLY

21

706-88-90140

PLATE

22

706-88-90150

DISC

23

706-88-90180

PISTON, BRAKE

24

07000-15240

O-RING

25

706-88-90130

RING, BACK-UP

26

07000-15270

O-RING

27

07001-05270

RING, BACK-UP

28

706-88-90410

SPRING
