Запчасти Komatsu PC300LC-6LE FIG. P-A КОНЕЧНАЯ ПЕРЕДАЧА НИЖНЯЯ ГИДРОЛИНИЯ И ЛИНИЯ ХОДА

|$2

207-27-00310

SEAL ASSEMBLY, FLOATING

|$3

170-27-00115

RING ASSEMBLY, SEAL

2

207-27-61331

RING

|$5

207-27-00320

O-RING ASSEMBLY

3

170-27-12520

O-RING

4

207-27-63190

HUB

5

207-27-63220

BEARING

6

207-27-51292

COVER

7

01010-81230

BOLT

8

01643-31032

WASHER

9

207-27-63240

O-RING

10

207-27-61270

LOCK

11

207-27-61261

NUT

12

01010-81020

BOLT

13

207-27-63170

CARRIER, 2ND

14

207-27-63140

GEAR

15

207-27-63210

BEARING

16

20Y-27-21250

WASHER

17

207-27-63230

PIN

18

20Y-27-21330

PIN

19

20Y-27-13310

WASHER, THRUST

20

207-27-63130

GEAR, SUN

21

207-27-63150

GEAR, RING

22

207-27-63250

WASHER

23

207-27-63160

CARRIER, 1ST

24

207-27-63120

GEAR

25

207-27-61220

BEARING

26

20Y-27-21240

WASHER, THRUST

27

207-27-61240

PIN

28

20Y-27-21280

PIN

29

208-27-61111

SHAFT

30

20Y-27-11250

SPACER

31

208-27-61350

BUTTON

32

207-27-63180

COVER

33

01011-61880

BOLT

34

01643-31845

WASHER

35

07049-01215

PLUG

36

07044-12412

PLUG

37

07002-12434

O-RING

38

207-27-61210

SPROCKET

39

207-27-51311

BOLT

40

01010-82075

BOLT

41

01643-32060

WASHER

42

207-30-61241

BOLT

43

01010-61640

BOLT

44

01643-31645

WASHER
