Запчасти Komatsu PC300LC-6LE FIG. N-A МОТОР ПОВОРОТА - COMPLETE ASSEMBLY ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$0

706-77-01281

MOTOR ASSEMBLY, SWING (COMPLETE)

|$1

706-77-03130

MOTOR SUB ASSEMBLY

1

706-77-43210

CASE, MOTOR

2

706-77-72610

HOUSING

3

706-75-42830

PIN

4

706-77-72170

PLUG

5

07002-12434

O-RING

6

706-73-71450

PIN

7

07002-11423

O-RING

8

706-7G-40010

BEARING

9

706-7E-11440

O-RING

10

706-77-43180

BOLT

11

706-77-43860

SHAFT

12

706-77-43880

BEARING

13

706-77-42890

BEARING

14

706-77-42051

SPRING

15

706-77-42041

SEAT

16

706-77-05010

KIT, SPACER

|$18

706-77-42440

SPACER, 2.30 mm

|$19

706-77-42450

SPACER, 2.50 mm

|$20

706-77-42460

SPACER, 2.70 mm

17

04064-06525

RING

18

706-77-43950

SEAL

19

706-77-43060

COVER

20

07000-02125

O-RING

21

04071-00130

RING

22

706-77-43191

BLOCK, CYLINDER

23

706-77-43840

PLATE

24

708-18-13230

PIN

25

706-77-43080

SHAFT, CENTER

26

706-77-42130

RING, CENTER

27

706-77-42110

SPRING

|$32

706-77-05050

KIT, RETAINER

28

706-77-43260

RETAINER

29

706-75-41271

SCREW

30

706-77-42160

PISTON

31

706-77-91540

PLATE

32

706-77-91550

DISC

33

706-77-91580

PISTON

34

07000-15180

O-RING

35

708-8H-15220

O-RING

36

706-77-91510

SPRING
