Запчасти Komatsu PC300LC-6LE FIG. N-A МЕХАНИЗМ ПОВОРОТА ПОВОРОТН. КРУГ И КОМПОНЕНТЫ

|$0

207-26-00160

SWING MACHINERY ASSEMBLY

1

207-26-62170

CASE

2

06000-22222

BEARING

3

06000-22326

BEARING

4

207-26-54263

COVER

5

01010-81040

BOLT

6

01643-31032

WASHER

7

207-26-61210

SEAL

8

207-26-62180

SHAFT

9

207-26-62150

COUPLING

10

207-26-54230

PLATE

11

205-32-51211

BOLT, SHOE

|$12

205-32-05021

BOLT, SHOE

12

20Y-27-22170

CARRIER

13

20Y-27-22140

GEAR

14

20Y-27-22220

BEARING

15

20Y-27-21250

WASHER

16

20Y-27-21230

PIN

17

20Y-27-21290

PIN

18

207-26-62190

GEAR

19

20Y-27-13310

WASHER

20

20Y-27-22240

WASHER

21

207-26-62130

GEAR

22

207-26-62140

CARRIER

23

207-26-62120

GEAR

24

20Y-27-22210

BEARING

25

20Y-27-21240

WASHER

26

20Y-27-21220

PIN

27

20Y-27-21280

PIN

28

207-26-61180

GUIDE

29

207-26-62110

GEAR

30

20Y-27-21310

WASHER

31

207-26-62160

COVER

32

20Y-27-13281

BOLT

33

01643-31645

WASHER

34

07042-00108

PLUG

35

07730-40004

VALVE

36

207-26-31220

TUBE

37

07281-00197

CLAMP

38

07000-15290

O-RING

39

01010-82480

BOLT

|$41

01010-62480

BOLT

40

01643-32460

WASHER

41

20Y-26-21340

GAUGE

42

20Y-26-21350

FILLER
