Запчасти Komatsu PC300LC-6LE FIG. K-A OPERATOR КАБИНА - ПЕРЕДН. ОКНА КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$0

20Y-54-36705

WINDOW ASSEMBLY, FRONT

1

20Y-54-36713

WINDOW, FRONT

2

20Y-54-38122

GLASS

3

20Y-54-38133

STRIP, WEATHER

4

20Y-54-38143

SEAL

5

20Y-54-38152

SEAL

6

20Y-54-43130

LATCH ASSEMBLY, LH

7

20Y-54-43150

KNOB

6

20Y-54-43140

LATCH ASSEMBLY, RH

7

20Y-54-43150

KNOB

8

01435-30816

BOLT

9

20Y-54-14290

STOPPER

10

01580-11008

NUT

11

20Y-54-14590

HANDLE

12

01023-10616

SCREW

13

20Y-54-14310

STRIKER

14

20Y-54-14280

SCREW

15

20Y-54-37810

STOPPER, LH

16

01023-70416

SCREW

17

20Y-54-37820

STOPPER, RH

18

01023-70416

SCREW

19

20Y-54-36835

BLOCK, LH

19

20Y-54-36845

BLOCK, RH

20

01252-50635

BOLT

21

01641-50608

WASHER

22

20Y-54-39152

ROLLER

23

205-54-63310

LOCK ASSEMBLY

24

01435-30820

BOLT

25

20Y-54-39363

BRACKET

26

01435-30820

BOLT

27

154-61-16570

WASHER

28

08074-40000

SWITCH

29

20Y-54-39590

HARNESS, WIRING

30

20Y-54-36150

GROMMET

31

08051-00801

CLIP

32

20Y-54-14721

LOCK

33

01435-30820

BOLT

|$43

20Y-54-36103

WINDOW ASSEMBLY, LOWER

34

20Y-54-36122

LATCH ASSEMBLY, LH

36

20Y-54-36132

LATCH ASSEMBLY, RH

35

20Y-54-36142

PLATE

36

20Y-54-36191

GROMMET

37

01225-70612

SCREW

38

20Y-54-36211

COVER

39

20Y-54-36113

GLASS

40

20Y-54-36171

SEAT

41

20Y-54-36230

SHIM

42

01370-00620

SCREW

43

01643-30623

WASHER

44

20Y-54-36182

STOPPER

45

01435-30820

BOLT

N/I

20Y-00-A2130

DECAL, FRONT WINDOW SHADE
