Запчасти Komatsu PC300LC-6LE FIG. A-AA ГОЛОВКА ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6742-01-5530

HEAD, CYLINDER

1

NSS

HEAD, CYLINDER

2

1296 803 H1

PLUG, EXPANSION

3

6742-01-2920

PLUG, EXPANSION

4

6736-21-1810

PLUG, EXPANSION

5

6742-01-3240

GUIDE, VALVE STEM

6

1307 586 H1

INSERT, VALVE - EXHAUST

7

1241 223 H2

INSERT, VALVE - INTAKE

8

6742-01-2960

PLUG, PIPE (1/16 NPT)

9

6732-61-2240

PLUG, PIPE (1/4 NPT)

10

6732-11-1910

PLUG, PIPE (1/2 NPT)

11

6742-01-5224

SEAL, VALVE STEM - INTAKE

|$12

1296 823 H1

VALVE, ASSEMBLY, EXHAUST

12

NSS

VALVE, INTAKE

13

6742-01-2990

COLLET, VALVE

|$15

6742-01-3000

VALVE, ASSEMBLY, EXHAUST

14

NSS

VALVE, EXHAUST

15

6742-01-2990

COLLET, VALVE

16

6732-21-5170

WASHER, SEALING

17

6736-21-5320

PLUG, THREADED (M22-1.50)

18

6741-41-4410

SPRING, VALVE

19

6742-01-3030

RETAINER, VALVE SPRING

20

6742-01-5224

SEAL, VALVE STEM - EXHAUST

21

6742-01-3250

PLUG, EXPANSION

22

1294 847 H2

COUPLING, ELBOW HOSE

23

6742-01-5582

GASKET, CYLINDER HEAD

24

6742-01-3270

BOLT (M14-2.00x80)

25

6743-11-1610

BOLT (M14-2.00x160)

|$31

6742-01-5172

GASKET, CYLINDER HEAD 0.25MM OVERSIZE

|$32

6742-01-5174

GASKET, CYLINDER HEAD 0.50MM OVERSIZE
