Запчасти Komatsu PC300LC-6LE FIG. A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

|$0

6741-22-1110

BLOCK ASSEMBLY, CYLINDER

1

NSS

BLOCK, CYLINDER

2

6742-01-1360

PLUG, EXPANSION

3

6742-01-1370

PLUG, EXPANSION

4

6742-01-1380

PLUG, EXPANSION

5

6736-21-1810

PLUG, EXPANSION

6

6742-01-5160

BUSHING

7

6741-21-1130

CAP, MAIN BEARING

8

6742-01-1420

PLUG, EXPANSION

9

6741-21-1140

BOLT (M14-2.00x135)

|$10

6742-01-5159

LINER KIT, CYLINDER

10

NSS

LINER, CYLINDER

11

6742-01-1520

SEAL, RECTANGULAR RING

|$13

6742-01-1440

HARDWARE KIT, CYLINDER BLOCK

|$14

6742-01-1380

PLUG, EXPANSION

12

6216-94-3450

DRAINCOCK

13

6735-21-5530

PLUG, EXPANSION

14

6732-11-1910

PLUG, PIPE (1/2 NPT)

15

6732-11-1920

PLUG, PIPE (3/4 NPT)

16

6742-01-1460

PLUG, PIPE (1 NPT)

17

6732-21-6120

DOWEL, PIN (M10-16)

18

6742-01-1470

DOWEL, PIN

19

6742-01-1480

PLUG, EXPANSION

20

6742-01-3890

NOZZLE, PISTON COOLING

21

6732-11-1930

PLUG, PIPE (1/8 NPT)

|$25

1296 695 H1

SHIM, COUNTERBORE SERVICE - 0.010 IN OS

|$26

1296 696 H1

SHIM, COUNTERBORE SERVICE - 0.015 IN OS

|$27

1296 697 H1

SHIM, COUNTERBORE SERVICE - 0.020 IN OS

|$28

1296 698 H1

SHIM, COUNTERBORE SERVICE - 0.030 IN OS

|$29

1296 699 H1

SHIM, COUNTERBORE SERVICE - 0.040 IN OS
