Запчасти Komatsu PC300LC-6LE FIG. H-A ОСНОВН. ГИДР. НАСОС. - CRADLE ASSEMBLY ГИДРАВЛИКА

1

708-2H-22120

SHAFT

2

708-1H-12151

BEARING

3

708-17-05010

KIT, WASHER

|$5

NSS

WASHER, 3.0 mm

|$6

NSS

WASHER, 3.1 mm

|$7

NSS

WASHER, 3.2 mm

4

708-17-12780

RING, RETAINING

|$9

708-2H-04150

CYLINDER BLOCK ASSEMBLY

5

708-2H-23160

BLOCK CYLINDER

6

708-2H-23240

PLATE, VALVE

7

708-2H-23350

RETAINER, GUIDE

8

708-2H-23151

SPRING

9

708-2H-23130

SEAT

10

708-2H-23141

SEAT

11

04065-05820

RING, RETAINING

12

708-2H-23360

PIN

13

708-2H-23340

RETAINER, SHOE

14

708-2H-23311

PISTON

|$20

708-2H-04160

CRADLE ASSEMBLY

15

708-2H-23850

CRADLE

16

708-2H-23450

CAM, ROCKER

17

04020-01434

PIN

18

706-75-40340

BOLT

19

07000-B1009

O-RING
