Запчасти Komatsu PC300LC-6LE FIG. H-A ОСНОВН. УПРАВЛЯЮЩ. КЛАПАН (+ АКТУАТОРS) - PRESSURE COMPENSATION КЛАПАНS ГИДРАВЛИКА

1

723-46-41110

VALVE

2

723-46-41120

VALVE

|$4

723-46-40100

VALVE, PRESSURE COMPENSATION

3

NSS

SLEEVE

4

NSS

PISTON

5

NSS

SPRING

6

723-46-41940

SEAL

7

700-93-11320

O-RING

8

723-46-41950

RING

9

07002-13634

O-RING

|$12

723-46-40300

VALVE, PRESSURE COMPENSATION

10

NSS

SLEEVE

11

NSS

PISTON

12

NSS

SPRING

13

723-46-41940

SEAL

14

700-93-11320

O-RING

15

723-46-41950

RING

16

07002-13634

O-RING

|$20

723-46-40601

VALVE, PRESSURE COMPENSATION

17

NSS

SLEEVE

18

NSS

PISTON

19

NSS

SPRING

20

723-46-41940

SEAL

21

700-93-11320

O-RING

22

723-46-41950

RING

23

07002-13634

O-RING

|$28

723-46-43100

VALVE, PRESSURE COMPENSATION

24

NSS

SLEEVE

25

NSS

PISTON

26

NSS

SPRING

27

NSS

SEAL

28

700-93-11320

O-RING

29

723-46-41950

RING

30

07002-13634

O-RING

|$36

723-46-43200

VALVE, PRESSURE COMPENSATION

31

NSS

SLEEVE

32

NSS

VALVE SUB ASSEMBLY

33

NSS

SPRING

34

723-46-42930

SEAL

35

700-93-11320

O-RING

36

723-46-41950

RING

37

07002-13634

O-RING

38

723-46-41980

RETAINER

|$45

723-46-44100

VALVE, PRESSURE COMPENSATION

39

NSS

SLEEVE

40

NSS

PISTON

41

NSS

SPRING

42

723-46-42910

SEAL

43

700-93-11320

O-RING

44

723-46-41950

RING

45

07002-13634

O-RING

|$53

723-46-45100

VALVE, PRESSURE COMPENSATION

46

NSS

SLEEVE

47

NSS

PISTON

48

NSS

SPRING

49

723-46-42920

SEAL

50

700-93-11320

O-RING

51

723-46-41950

RING

52

07002-13634

O-RING
