Запчасти Komatsu PC300LC-6LC FIG. T-A ЦИЛИНДР СТРЕЛЫ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

207-63-02501

CYLINDER ASSEMBLY, BOOM

1

207-63-53541

BARREL, CYLINDER

2

707-76-90390

BUSHING

3

07145-00090

SEAL, DUST

4

07020-00675

FITTING, GREASE

5

07043-00108

PLUG

6

207-63-53520

ROD

7

707-76-10130

BUSHING

8

07145-00100

SEAL, DUST

9

707-71-32880

COLLAR

10

707-35-91420

RING

11

07000-15130

O-RING

12

707-71-61060

PLUNGER

13

707-27-14930

HEAD

14

176-63-56170

SEAL, DUST

15

07179-13114

RING, SNAP

16

707-52-90780

BUSHING

17

707-51-10030

PACKING, ROD

18

707-51-10630

RING, BUFFER

19

707-35-91420

RING, BACK-UP

20

07000-15130

O-RING

21

01010-81875

BOLT

22

707-41-11840

WASHER

23

707-36-14410

PISTON

24

01310-01216

SCREW

25

707-44-14180

RING, PISTON

26

707-39-14820

RING, WEAR

27

707-44-14910

RING

28

07001-05090

RING, BACK-UP

29

07000-15090

O-RING

30

207-63-53171

TUBE, LH

|$31

207-63-53271

TUBE, RH

31

207-63-53181

TUBE, LH

|$33

207-63-53281

TUBE, RH

32

01435-01055

BOLT

33

07000-13035

O-RING

34

707-88-95731

BRACKET LH

35

707-88-95720

BAND

36

01010-81240

BOLT

37

01643-51232

WASHER

38

07283-23442

U-BOLT

39

01643-31032

WASHER

40

01599-01011

NUT

41

01010-81025

BOLT

42

01643-31032

WASHER

|$45

707-99-58360

SEAL KIT
