Запчасти Komatsu PC300LC-6LC FIG. R-A ГУСЕНИЦЫ - ТРОЙНОЙ ГРУНТОЗАЦЕП. С ОТВЕРСТИЯМИ (ДЛЯ PCLC) ХОДОВАЯ

|$3

207-32-03681

SHOE ASSEMBLY, TRACK

1

207-32-61110

SHOE, TRACK (600 mm / 23.6 INCH)

2

207-32-51210

BOLT, SHOE

3

207-32-51220

NUT, SHOE

|$7

207-32-00151

LINK ASSEMBLY, TRACK

4

207-32-61121

LINK, LH TRACK

5

207-32-61131

LINK, RH TRACK

6

207-32-51140

BUSHING, REGULAR

7

144-32-11240

SEAL, DUST (REGULAR)

8

207-32-61150

PIN, REGULAR

9

207-32-51170

BUSHING, MASTER

10

207-32-61260

SEAL, DUST (MASTER)

11

207-32-61190

PIN, MASTER

|$19

207-32-03691

SHOE ASSEMBLY, TRACK

|$20

207-32-61310

SHOE, TRACK (600 mm / 23.6 INCH)

|$21

207-32-51210

BOLT, SHOE

|$22

207-32-51220

NUT, SHOE

|$23

207-32-00151

LINK ASSEMBLY, TRACK

|$27

207-32-3701

SHOE ASSEMBLY, TRACK

|$28

207-32-61320

SHOE, TRACK (600 mm / 23.6 INCH)

|$29

207-32-51210

BOLT, SHOE

|$30

207-32-51220

NUT, SHOE

|$31

207-32-00151

LINK ASSEMBLY, TRACK

|$35

207-33-03711

SHOE ASSEMBLY, TRACK

|$36

207-32-61340

SHOE, TRACK (600 mm / 23.6 INCH)

|$37

207-32-51210

BOLT, SHOE

|$38

207-32-51220

NUT, SHOE

|$39

207-32-00151

LINK ASSEMBLY, TRACK

|$43

207-32-05030

SERVICE KIT, SHOE BOLT AND NUT

|$44

207-32-51210

BOLT, SHOE

|$45

207-32-51220

NUT, SHOE
